YANMAR MARINE ENGINES FOR SAIL YACHTS

L’AGUILA II

L’Aguila II: A sail yacht powered by Yanmar marine engines

The 42-meter sail yacht L’Aguila II, designed by Ginton Naval Architects and built by Mengi-Yay in 2021, is powered by two reliable, performant and efficient Yanmar 6AYM-WGT high-speed engines, producing 1822 mhp.

Photo gallery

Inside the engine room: two Yanmar 6AYM-WGT-369 engines

Two powerful and efficient Yanmar 6AYM-WGT-369 high-speed diesel engines producing 1822 horsepower, effortlessly propel the L’Aguila II to impressive speeds while delivering remarkable fuel efficiency.

Designed with a lightweight and compact profile, these advanced engines are tailor-made for propelling high-performance sail yachts. Equipped with cutting-edge electronic control systems and advanced combustion technology, the 6AYM-WGT engines offer precise handling, reduced emissions and the reliability and durability essential for sail yacht propulsion.

As the driving force behind the L’Aguila II, these Yanmar engines enable cruising at 10 knots or reaching impressive top speeds of 15 knots, ensuring a reliable and durable performance that makes it the ultimate sail yacht for global exploration.

Main engine characteristics

Engine model: 6AYM-WGT L-rating
Rated output: 670 kW / 911 mhp
Rated engine speed: 1938
Displacement: 20.4 ltr (1244.9 cu in)
Bore x stroke: 155 mm x 180 mm
Number of cylinders: 6
Dimensions (L×W×H): 2000×1305×1431 mm
Engine type: 4-stroke, vertical water cooled diesel engine

Marine gear specifications

Model: YXH-240
Type: Hydraulic multi-disc clutch
Reduction ratio (Ahead): 1.95 2.27 2.56 3.03 3.48
Direction of rotation (propeller shaft): Clockwise or counterclockwise
Dry weight: 645 kg
